The integrated water cooling radiator can be said to be a reduced version of the split water cooling radiator. It is generally composed of water cooling head, water pump, radiator, water pipe, water cooling liquid and fan. Because of its physical properties, the thermal conductivity of water is not better than that of metal, but the flowing water has excellent thermal conductivity, that is, the heat dissipation performance of water cooling radiator is directly proportional to the flow rate of cooling liquid, The flow rate of refrigerant is related to the power of water pump in the refrigeration system.
Working Principle:
The integrated water cooling radiator transmits the heat of the CPU to the water-cooling liquid through the water cooling head. The water cooling liquid circulates to the water cooling row through the water pump, and then circulates again. Moreover, the heat capacity of the water is large, which makes the water cooling refrigeration system have a good heat load capacity. The direct benefit is that the working temperature curve of the CPU is very flat.
Influencing Factors Of Heat Dissipation Performance:
The heat dissipation efficiency of the integrated water cooling radiator is mainly related to three factors:
1. Design of water cooling head. The water cooling head is in direct contact with the CPU, and rapid heat conduction is very important. Generally, the water cooling head is in contact with the CPU with copper, and a micro water channel will be designed on the side in contact with the water cooling night, which can not only increase the contact area, but also increase the flow rate, so that the water cooling liquid can take more heat away. Different designs of water channels will bring different heat dissipation effects.
