Core selling point
1. Maximum Surface Area in a Single Unit
The 480mm-class aluminum core delivers the largest heat-exchange surface in this series, absorbing heavy loads from industrial lasers, medical imaging, and high-density servers. Extended fin length and flat micro-channel tubes stabilize coolant temperature through full-load duty cycles.
2. One Unit Replaces Multiple Smaller Radiators
One 480mm radiator matches the dissipation capacity of two 240mm units in a single mounting bay, cutting hardware count, tubing, and potential leak points. Fewer components mean faster assembly, simpler spare-part inventory, and lower installed cost for integrators and OEMs.
3. Dual G1/4 Ports for Clean Loop Integration
Dual G1/4 ports on the end tank accept standard fittings and quick couplings across industrial cooling architectures. Single-end inlet and outlet routing simplifies tubing paths in laser systems, medical equipment, and rack-based thermal management, cutting installation time and leak risk.
4. Four-Fan Airflow for Power and Quiet
Four 120mm fan stations across the 480mm frame deliver high total airflow at moderate speeds, keeping noise low for medical diagnostic rooms and laboratory workstations. The layout also accepts high-static-pressure fans when cooling dense racks or sealed enclosures demands maximum throughput.
5. 100% Leak-Tested Brazed Core
Every unit is 100% air-pressure leak tested before shipment, and the fully brazed aluminum core eliminates joint fatigue risk. Consistent fin pitch and flat-tube alignment ensure uniform airflow across the 480mm length, protecting pumps and sustaining performance through years of 24/7 duty.
6. Built for High-TDP Industrial Scaling
Built for high-TDP reliability, this radiator supports laser cutting and marking equipment, beauty instrument cooling, new energy vehicle charging stations, semiconductor systems, and AI computing clusters. A single 480mm unit per loop cuts chassis count and spare-part complexity for OEMs.
Product Parameters:
Model:AT480
Material:Pure aluminum
Water supply quantity:12
Fan size:120*120mm X4
Screw specification:6-32-31 (16), 6-32-8 (16)
Net weight:About 545g
Connector method:G1/4 thread
Surface treatment:The surface is treated with baking finish
Size:520*120*27mm（L*W*H）
Tightness test:0.2Mpa
Application:For PC water cooling system, industrial variable frequency drive, laser head cooling, industrial control cabinet and other cooling
Remarks:
The water tube is designed under the screw hole, it will be pierced by long screws.
Please do not use long screws.If such misuse that is not covered by product warranty!
Packages:
1 X Water Cooling Radiator
32X Screws
